all in one touch screen pos machine

1366*768 Resolution 15.6 Inch Intel Core I3 Capacitive Touch Screen All in One POS System

POS1528WB-I3
15.6 inch all in one pos
1366*768 resolution(1920*1080 OEM)
capacitive touch panel
CPU:I3(J3455, J1900, I5 OEM)
RAM:4GB(8GB OEM)
SSD:32GB(64GB, 128GB OEM)
Delivery
EXW
minimum order
1 piece
Supply Ability
2000piece / Month
Country of Origin
China
Stock Time
7Day
CPU:
J1800
J3455
J1900
I3
I5
I7
Size:
15.6 inch
RAM:
4GB
8GB
SSD:
32GB
64GB
128GB
Touch panel Type:
capacitive touch
Quantity:
US $273.00 - US $451.00 / piece
Contact Now
add to cart
Model No.POS1528WB-I3
Main Board
CPUIntel® Core™ I3 Processor (3M Cache, 1.70 GHz)，17W
ChipsetIntel® HM77
MotherboardThe core CPU integrated HD display
System MemoryDDRIII 1066/1333MHz 4GB,1*DIMM (max 8GB)
OS SupportWin 7,Win 8,win 10, Linux
Storage
SSDIndustrial 64G (128G SSD or 500G HDD（2.5"SATA))
SATA Slot1 * mSATA Slot
Display
LCD PanelIndustrial  15.6"TFT  LED(15” optional)
Resolution1366*768 (max) @ 60Hz(1920*1080 OEM)
Brightness300 cd/㎡
Ilting Angle35-90 Degree
Touch ScreenAll planar capacitive touch panel
I/O Ports
USBUSB2.0*4+USB3.0*2
Serial1* COM（DB9)(5*COM optional)
LAN1 * Realtek FE LAN chip (10/100/1000 Mbps)
VGA1 * VGA（DB15）
AudioALC662 5.1 Channel HDA Codec , Support MIC/Line-out Ports
DC1 * DC Power Input
Environment
PowerDC 12V 5A
Operating Temperature0℃ to 40℃
Storage Temperature－20℃ to 60℃
Other Optional11.6inch, 12.1Inch &15.6inch Second Display,Wifi, MSR optional
touch screen pos machine 15.6 inch
touch screen pos machine 15.6 inch pos terminal




all in one touch screen pos machine



15.6” TFT LED Panel

1366*768(max)@60Hz

Capacitive touch panel

Sensistive Touch







15.6 inch all in one touch screen pos machine

CPU:Intel Core I3

RMA: 4GB up to 8GB

Support Win7/8/10, Linux

The core CPU integrated HD display

touch screen pos machine 15.6 inch pos terminal

touch screen pos machine 15.6 inch





all in one touch screen pos machine



VFD 220 Customer display

11.6 Inch, 12.1 Inch Second Display Optional


15.6 inch all in one touch screen pos machine with win 10/11 linux
touch screen pos machine 15.6 inch with win 7 8 10 linux pos terminal
touch screen pos machine 15.6 inch
white black color 15.6 inch all in one touch screen pos machine optional
white black color touch screen pos machine 15.6 inchtouch screen pos machine 15.6 inchtouch screen pos machine 15.6 inchtouch screen pos machine 15.6 inch
      all in one touch screen pos machine with multi interface
touch screen pos machine 15.6 inch
