| Model No. | POS1518-I3 |
| Main Board | |
| CPU | Intel® Core™ i3-4010U Processor (3M Cache, 1.70 GHz)，17W |
| Chipset | Intel® HM77 |
| Motherboard | The core CPU integrated HD display |
| System Memory | DDRIII 1066/1333MHz 4GB,1*DIMM (max 8GB) |
| OS Support | Win 7,Win 8,win 10, Linux |
| Storage | |
| SSD | Industrial 32G 64G 128G SSD or 500G HDD（2.5"SATA) |
| SATA Slot | 1 * mSATA Slot |
| Display | |
| LCD Panel | Industrial 15"TFT LED( 15.6”, 17” optional) |
| Resolution | 1024*768 (max) @ 60Hz(1920*1080 OEM) |
| Brightness | 300 cd/㎡ |
| Ilting Angle | 35-90 Degree |
| Touch Screen | All planar capacitive touch panel |
| I/O Ports | |
| USB | USB2.0*4+USB3.0*2 |
| Serial | 1* COM（DB9)(5*COM optional) |
| LAN | 1 * Realtek FE LAN chip (10/100/1000 Mbps) |
| VGA | 1 * VGA（DB15） |
| Audio | ALC662 5.1 Channel HDA Codec , Support MIC/Line-out Ports |
| DC | 1 * DC Power Input |
| Environment | |
| Power | DC 12V 5A |
| Operating Temperature | 0℃ to 40℃ |
| Storage Temperature | －20℃ to 60℃ |
| Other Optional | 12.1inch, 15Inch &15.6inch Second Display,Wifi, MSR , Printer optional |
15 inch pos cash register 15 inch pos terminal
15 inch pos cash register
LCD Panel: Industrial 15"TFT LED
Resolution: 1024*768(max)@60Hz
Touch Panel: True Flat capacitive touch
Sensistive Touch
15 inch pos terminal
15 inch pos terminal
CPU: Intel Core I3
Memory: Support DDR3L, 4GB up to 8GB
OS Support: Win7 /8 /10, Linux
The core CPU integrated HD display
15 inch pos cash register
All in one capacitive 15 inch pos terminal
with VFD220 Customer Display
LED8 and 15 Inch Second Display optional
15 inch pos cash register 15 inch pos terminal
15 inch pos cash register 15 inch pos terminal
15 inch pos cash register 15 inch pos terminal
15 inch pos cash register Square Capacitive touch screen 15 inch pos terminal
used for most areas, such as store, coffee, Pizza...
used for most areas, such as store, coffee, Pizza...
